Khoom Taw Qhia
GE IC693 CPU374 yog nruab nrog tus tswj hwm Ethernet, muaj ob lub chaw nres nkoj Ethernet nrog lub peev xwm tshawb pom tsis siv neeg, hloov sab hauv, thiab kev sib txuas lus ceev txog li 100Mbps rau cov khoom siv Ethernet. Nws txhawb SRTP, Ethernet cov ntaub ntawv thoob ntiaj teb, thiab Modbus / TCP tus neeg siv khoom / tus neeg siv khoom raws tu qauv, ua kom siab - cov ntaub ntawv ceev ceev nrog cov khoos phis tawj sab saud, lwm PLCs, thiab lwm yam khoom siv, thiab ua tau raws li cov kev cai ntawm kev lag luam Ethernet networking.
Technical Specifications
|
Kev tsim khoom |
GE |
|
Qauv |
TIAB SA 693CPU374 |
| Tshooj Naj Npawb | TIAB SA 693CPU374 |
|
Kev piav qhia |
Tib - qhov CPU module |
|
Keeb kwm |
Teb chaws USA |
|
Dimension |
30 * 25 * 5cm |
|
Qhov hnyav |
0.55kg ib |
IC693CPU374 Khoom nta thiab qhov zoo
Kev sib xyaw ua ke heev
Ib qho -slot module koom ua ke Ethernet, ntau qhov chaw nres nkoj thiab Genius tsheb npav tswj hwm, txo qhov xav tau rau kev sib txuas lus sab nraud, ua kom yooj yim tsim qauv, thiab txuag nqi thiab chaw.
Kev ua tau zoo
Kev soj ntsuam ceev ceev thiab cov neeg siv lub cim xeeb loj, muaj peev xwm tuav tswj cov txheej txheem nyuaj, ntau cov ntsiab lus I / O thiab cov ntaub ntawv teev cov haujlwm.
Muaj zog network txuas
Natively txhawb ntau-txheej tes hauj lwm nyob rau theem kev lag luam (Ethernet), qib ntaus ntawv (Genius Bus), thiab serial ntaus qib, pab txhawb kev sib koom ua ke.
IC693CPU374 Qhov System nthuav dav thiab I / O muaj peev xwm
Local backplane expansion
Txhawb kev teeb tsa ntawm ntau yam 90-30 series I / O modules thiab tshwj xeeb muaj nuj nqi modules ntawm cov racks hauv zos.
Tej thaj chaw deb expansion muaj peev xwm
Los ntawm kev siv expansion receiver modules xws li IC693BEM331 thiab expansion cables, tej thaj chaw deb expansion racks tuaj yeem txuas ntxiv kom muaj peev xwm I/O ntxiv.
Core Performance Parameters
Processor thiab nco: High -kev ua tau zoo 32-ntsis processor tau txais yuav.
Tus neeg siv logic nco: 256 KB.
Tus neeg siv cov ntaub ntawv sau npe nco: 512 KB.
Kev ua kom ceev: Qhov kev ntsuas nrawm nrawm yog 0.15 milliseconds ib txhiab Boolean cov lus qhia, ua rau nws yog ib qho ntawm CPU ceev tshaj plaws hauv 90-30 series.
Lub cev specification: Ib qho - qhov dav dav tsim, txuag chaw khib.
Kev khiav hauj lwm kub: 0 degree rau 60 degree.
3. Ua - hauv kev sib txuas lus interface
IC693CPU374 yog lub npe nrov rau nws cov peev txheej sib txuas lus zoo heev, nrog rau nws lub vaj huam sib luag pem hauv ntej ua ke nrog ntau qhov chaw nres nkoj:
Serial kev sib txuas lus Chaw nres nkoj 1 (Port 1): Ib RS-232/RS-485 configurable chaw nres nkoj (9-pin D-sub). Nws feem ntau yog siv los ua qhov chaw nres nkoj programming, txhawb nqa SNP raws tu qauv kev sib txuas rau programming software (xws li Proficy Machine Edition), thiab tseem tuaj yeem teeb tsa ua Modbus RTU tus tswv lossis qhev chaw nres tsheb.
Serial kev sib txuas lus chaw nres nkoj 2 (Port 2): Ib RS-232/RS-485 configurable chaw nres nkoj (9-pin D-sub). Nws feem ntau yog siv los ua qhov chaw nres nkoj rau kev sib txuas ntawm tib neeg-tshuab interfaces, nyeem barcode, zaus hloov pauv lossis lwm yam khoom siv thib peb, thiab txhawb cov kev cai xws li SNP, Modbus RTU, thiab SRTP.
Serial kev sib txuas lus chaw nres nkoj 3 (Port 3): nOneRS-485 chaw nres nkoj (detachable terminal block). Nws feem ntau yog siv los ua qhov chaw sib txuas lus tshwj xeeb thiab tuaj yeem siv rau CPU-rau-CPU SNP kev sib txuas lus network.
Ethernet chaw nres nkoj: Tus qauv 10/100Mbps muaj Ethernet RJ45 chaw nres nkoj. Txhawb TCP/IP raws tu qauv pawg, tuaj yeem khiav SRTP (GE Fanuc ib txwm raws tu qauv) thiab Modbus TCP neeg rau zaub mov ua haujlwm, ua kom yooj yim rau siab -cov ntaub ntawv ceev sib pauv nrog lub khoos phis tawj sab sauv SCADA, lwm PLCS lossis Ethernet- cov khoom txhawb nqa.
Genius Bus chaw nres nkoj: Ua -hauv Genius tsheb npav maub los, txuas ncaj qha los ntawm lub davhlau ya nyob twg thaiv. Nws tuaj yeem tswj tau ncaj qha mus txog 32 Genius tsheb npav (xws li chaw taws teeb I / O chaw nres tsheb, zaus hloov pauv, sensors, thiab lwm yam), txhawb nqa tsheb npav rov ua dua, thiab yog lub luag haujlwm tseem ceeb rau kev ua tiav kev faib I / O thiab tswj.
Tej daim ntawv thov teb
Vim nws lub zog muaj zog, IC693CPU374 feem ntau siv rau hauv kev xav tau kev lag luam automation scenarios, xws li:
Complex loj - nplai tshuab tswj thiab ntau lawm kab saib xyuas.
Cov txheej txheem tswj cov txheej txheem (xws li hauv chemical engineering, dej kho, thiab tshuaj).
Cov khoom siv tuav thiab warehousing automation system.
Factory automation tej yaam num uas yuav tsum tau siab - ceev cov ntaub ntawv sib pauv thiab faib tswj.
