Khoom Taw Qhia
IC693CPU323 yog 10-slot embedded Turbo CPU baseboard hauv GE Fanuc 90-30 series. Nws nta 10 I / O slots thiab 1 nplooj siab lub hwj chim qhov, thiab yog sib xws nrog ntau yam yooj yim I / O modules ntawm 90-30 series. Nws tsuas yog nruab nrog ib qho yooj yim serial kev sib txuas lus chaw nres nkoj los ntawm nws tus kheej. Yog tias nws tau ua ke nrog cov kev xaiv kev sib txuas lus xws li Ethernet, Profibus, thiab GCM, nws tuaj yeem txuas nrog cov khoom lag luam sib txuas kom ua tiav cov ntaub ntawv sib cuam tshuam nrog lwm cov cuab yeej tswj hwm thiab cov khoos phis tawj sab saud, thiab hloov mus rau kev sib txuas lus ntawm cov xwm txheej sib txawv.
Technical Specifications
|
Tsim |
GE |
|
Qauv |
TIAB SA 693CPU323 |
| Tshooj Naj Npawb | TIAB SA 693CPU323 |
|
Kev piav qhia |
10-SLOT BASE nrog CPU |
|
Keeb kwm |
Teb chaws USA |
|
Dimension |
30 * 25 * 5cm |
|
Qhov hnyav |
0.55 kg ib |
IC693CPU323 Lub luag haujlwm tseem ceeb
Kev Ua Haujlwm thiab Tswj
Ua lub luag haujlwm rau siab - scanning ceev thiab ua kom tiav cov kev tswj xyuas uas tau sau los ntawm cov neeg siv (daim duab ntaiv, daim ntawv teev lus, daim duab thaiv kev ua haujlwm, thiab lwm yam).
Nws muab cov txheej txheem kev qhia dav dav thiab muaj zog, txhawb nqa txoj hauv kev yooj yim, kev ua lej, kev tswj cov ntaub ntawv thiab kev tswj cov txheej txheem.
Nco
Cov neeg siv cov kev pab cuam nco: Nws muab qhov loj - muaj peev xwm cia qhov chaw ntawm 64K bytes, uas yog siv los khaws cov txheej txheem tswj kev nyuaj thiab kev teeb tsa.
Cov ntaub ntawv sau npe nco: Nws muab 32K bytes ntawm qhov chaw cia, muab kev cia txaus rau ntau qhov sib txawv, arrays, thiab cov ntaub ntawv txheej txheem.
Lub cim xeeb hom yog RAM + lithium roj teeb thaub qab. Cov neeg siv cov kev pab cuam tuaj yeem khaws cia rau hauv qhov tsis yog - lub cim xeeb tsis zoo (flash memory).
Ua - hauv kev sib txuas lus interface
Ethernet interface: Integrate ib 10Base-T Ethernet chaw nres nkoj (RJ-45 interface). Qhov no yog nws qhov tseem ceeb tshaj plaws.
Txhawb SRTP raws tu qauv (GE's mob siab rau industrial Ethernet raws tu qauv) rau siab -cov ntaub ntawv ceev pauv nrog lub computer sab sauv (HMI/SCADA), programming workstations thiab lwm yam SRTP- pab kiag li lawm.
Txhawb Modbus TCP neeg rau zaub mov muaj nuj nqi, pab txhawb kev sib txuas lus nrog tus thib peb -cov software lossis cov khoom siv uas txhawb Modbus TCP (xws li HMI, MES systems).
IC693CPU323 Configuration thiab Programming
Programming software
Siv Proficy Machine Edition (PME) rau kev teeb tsa kho vajtse, kev sau ntawv, kev debugging thiab rub tawm. Nws tuaj yeem txuas nrog ntawm qhov chaw nres nkoj serial lossis Ethernet chaw nres nkoj.
Network configuration
Nws yog qhov tsim nyog los teeb tsa qhov chaw nyob IP tshwj xeeb, lub npog ntsej muag subnet thiab lub rooj vag rau CPU323 hauv PME software los pab txhawb kev sib txuas lus Ethernet.
Lub cev thiab installation specifications
Sab nraud qhov ntev: Standard 90-30 series single-slot CPU module, tab sis vim nws txoj haujlwm nyuaj, nws feem ntau yog me ntsis ntev dua li cov CPU yooj yim.
Kev teeb tsa qhov chaw: Nws yuav tsum tau muab tso rau hauv qhov chaw sab laug ntawm cov khib nyiab hauv zos ntawm Series 90-30 PLC.
Lub teeb taw qhia xwm txheej: Lub vaj huam sib luag tau nruab nrog ntau lub teeb qhia LED, suav nrog:
RUN/STOP: Khiav/Stopping state
BATT: Tsawg roj teeb lub zog
FAULT: Fault indication
COM1: Serial kev sib txuas lus ua haujlwm
COM2 (ETH): Ethernet port link/activity status indicator
Roj teeb: Lub roj teeb lithium yog siv rau lub hwj chim -tawm ntawm khaws cia ntawm RAM cov ntaub ntawv thiab rthe eal- lub sijhawm moos.
Technical Performance Parameters
Scanning ceev: Lub sij hawm scanning ib txwm yog 0.4 milliseconds ib K logic qhia, uas belongs rau lub siab -kawg kev ua tau zoo nyob rau hauv 90-30 series.
Muaj peev xwm nthuav dav: Txog li 2 qhov kev nthuav dav racks tuaj yeem txuas nrog (siv cov kab txuas ntxiv IC693CBL3xx), thiab tag nrho ntawm 3 racks tuaj yeem tswj tau.
Kev sib txuas lus chaw nres nkoj
1 x 10 BASE-T Ethernet chaw nres nkoj (RJ-45)
1 x RS-232/485 switchable serial chaw nres nkoj (9-pin D hom)
Txhawb kev cai: SRTP, Modbus TCP, FTP (Ethernet kawg); SNP, Modbus RTU (Serial Terminal)
Tej daim ntawv thov teb
Qhov CPU no tsim nyog rau cov ntawv thov nyuaj uas yuav tsum muaj siab -kev ua tau zoo ntawm kev tswj hwm, lub Hoobkas- theem cov ntaub ntawv sib koom ua ke, thiab kev tswj hwm kev sib txuas, xws li:
Loj - qhov chaw tuav thiab faib khoom
Complex manufacturing los ua ke kab thiab sib dhos kab
Kev soj ntsuam cov txheej txheem uas yuav tsum tau ua ke nrog lub Hoobkas xov xwm network (IT system)
Raws li qhov chaw nres tsheb hauv nruab nrab ntawm qhov nruab nrab - loj faib tswj qhov system.
