Khoom Taw Qhia
IC695CMU310 yog CPU module sib koom ua ke ob qhov chaw nres nkoj hauv PACSystems RX3i series ntawm programmable automation controllers, uas txhim kho nws qhov yooj yim hauv cov ntawv thov uas xav tau kev sib txuas rau cov khoom siv serial xws li qub -fashioned HMIs, nyeem barcode, modems, lossis lwm yam PLCS. Raws li "MAX ON" version, nws muab cov neeg siv nrog cov txheej txheem ua tiav uas tau npaj siv tawm ntawm lub thawv.
Technical Specifications
|
Kev tsim khoom |
GE |
|
Qauv |
SIB 695 CMU 310 |
| Tshooj Naj Npawb | IC 695 CMU 310-CJ |
|
Kev piav qhia |
MAX RAU RX3i 300Mhz CPU nrog ob lub SERIAL PORTS |
|
Keeb kwm |
Teb chaws USA |
|
Dimension |
30 * 15 * 5cm |
|
Qhov hnyav |
0.55kg ib |
Khoom Paub meej
Lub PACSystems RX3i Max-ON CPU IC695CMU310 muab Kub-CPU rov ua dua siv ob lub RX3i. Cov tswj tsis tu ncua hloov pauv cov ntaub ntawv ua haujlwm los ntawm ib lossis ob lub siab Ethernet LANs.Txhua RX3ii system hauv Max-Ntawm daim ntawv thov muaj Max-ON CPU (IC695CMU310)
RX3i Universal Backplane (lC695CHS0xx)
RX3i fais fab mov (lC695PSxxxx)
ib lossis ntau dua RX3i Ethernet modules (IC695ETM001)
Max -ON daim ntawv thov software
Optional Series 90-30 expansion backplanes.
PACSystems RX3i thiab / lossis Series 90-30 modules, raws li qhov tsim nyog rau daim ntawv thov.
Max-ON CPU yog sib xws nrog ntau yam ntawm RX3i thiab Series 90-30 modules, backplanes, thiab lwm yam khoom siv, raws li teev nyob rau hauv PACSystems RX3i Hardware thiab Installation Manual. KUB-2314.
Max-ON redundancy daim ntawv thov suav nrog kev thauj khoom roj, kev tsim hluav taws xob standby, lub tshuab boiler, thiab cov tshuab tsim khoom. Tus tswv Max-ON software muab cov txheej txheem subroutines rau synchronisation ntawm qhov sib txawv, kev ntsuas qhov sib npaug, xaiv tus tswv CPU, thiab kev kuaj mob. Thaum siv Max-ONredundancyy, kev hloov ntawm kev tswj los ntawm Master mus rau Backup tuaj yeem siv ob mus rau peb CPU logic scans. l/O xeev raug tswj xyuas thaum lub sij hawm hloov. Max-ON redundancy tsis haum rau SlL 2 lossis 3 daim ntawv thov.
Cov lus qhia rau kev txhim kho tseem ceeb rau roj teeb
Tsis txhob txuas lub roj teeb kom txog thaum CPU tau teeb tsa hauv lub khib nyiab thiab lub khib nyiab tau qhib. Lub roj teeb yuav txuas mus rau ob qho ntawm ob lub terminals nyob rau hauv lub roj teeb compartment. Thaum qhov no ua tiav, CPU yuav raug kaw, thiab lub roj teeb thaub qab yuav pib. Txhawm rau txuag lub roj teeb lub neej, tsis txhob txuas lub roj teeb thawj zaug kom txog thaum lub CP yog powered.
Kwv yees lub roj teeb lub neej nrog lub zog siv
Qhov nominal backup qhov tseem ceeb yog kwv yees li ntawm 20'c (68℃F). Lub sijhawm thaub qab nce kwv yees li 17% ntawm 60'c thiab txo qis li 32% ntawm 0 degree.
