Khoom Taw Qhia
Yokogawa AAI543-S00yog ib qho analog tso zis module uas yog siv nyob rau hauv DCS thiab automates tswj systems. Nws hloov cov lus qhia tswj digital tau txais los ntawm cov tswj hwm lossis cov tswj hwm tseem ceeb rau hauv cov cim analog tam sim no. Tus qauv tsim ntawm lub module yog ib qho kev sib cais tso zis channel tsim, ib tug qauv teb tam sim no tso zis ntau yam, thiab nws yuav siv tau nyob rau hauv txawv industrial tswj systems.
Technical Specifications
|
Hom |
YOKOGAWA |
|
Qauv |
AAI543-S00 |
|
Tshooj Naj Npawb |
AAI543-S00 S1 |
|
Kev piav qhia |
Analog Output Module |
|
Keeb kwm |
Singapore / Nyiv |
|
Dimension |
17 * 15 * 7cm |
|
Qhov hnyav |
0, 35kg |
Core Feature
Txheem tam sim no tso zis
AAI543-S00 outputs tus qauv 4-20 mA DC analog teeb liab, uas yuav siv tau rau kev tswj ntawm teb actuators, li qub, los yog lwm yam automation khoom.
Ntau-channel cais tawm tsim
AAI543-S00 Analog Output Module muab ntau yam kev ywj pheej tso tawm raws, uas pab txo cov teeb liab cuam tshuam thiab txhim kho lub teeb liab kev ncaj ncees ntawm lub cev.
Qhib Circuit Court detection muaj nuj nqi
AAI543-S00 Analog Output Module tuaj yeem kuaj xyuas qhov qhib qhov hluav taws xob ntawm qhov tso zis hluav taws xob. Thaum qhov tam sim no qis dua qhov chaw pib, nws ua rau lub tswb nrov lossis kev kuaj mob, ua kom muaj peev xwm txheeb xyuas qhov ua txhaum ntawm qhov chaw.
Kev them nyiaj yug rau redundant configuration
Hauv multi-module redundant configuration, cov khoom no txhawb cov qauv hloov cov lus teb thiab tuaj yeem teeb tsa nrog dual -module redundant mechanism raws li qhov yuav tsum tau ua.
HART kev sib txuas lus xaiv
Qee cov qauv lossis kev cuam tshuam nrog cov kev xaiv tuaj yeem txhawb nqa HART raws tu qauv, uas yog siv rau kev sib txuas lus nrog cov cuab yeej ntse ntse thiab kev hloov pauv.
Core Advantage
Txheej txheem tswj compatibility
AAI543-S00 Analog Output Module tuaj yeem ua haujlwm ua ke nrog ntau lub DCS platforms (xws li Yokogawa CENTUM VP), pab txhawb kev koom ua ke rau hauv cov txheej txheem tswj hwm uas twb muaj lawm.
Kev rho tawm ntawm cov zis ua kom cov teeb liab stability.
Kev sib cais tsim rau txhua qhov channel ntxiv dag zog rau kev tiv thaiv - muaj peev xwm cuam tshuam, uas pab tswj kev ruaj ntseg ntawm cov teeb liab tso tawm hauv thaj chaw nyuaj.
Diagnostic muaj nuj nqi txhawb rau ntawm - kho qhov chaw.
Qhov qhib -Kev kuaj xyuas lub voj voog ua haujlwm, ua ke nrog kev kuaj xyuas lub cev, tuaj yeem pab ntawm - cov neeg ua haujlwm saib xyuas qhov chaw txheeb xyuas cov xwm txheej txawv txav hauv cov kab lossis cov sensors ntxov li sai tau.
Haum rau industrial installation ib puag ncig
AAI543-S00 Analog Output Module yog tsim los rau kev teeb tsa ntawm DIN rail ntawm kev tswj cov txee lossis racks, thiab tuaj yeem hloov kho rau cov khoom siv hluav taws xob thiab ib puag ncig.
Haum rau ntau yam kev thov scenarios
Tsim nyog rau cov xwm txheej xws li kev tswj cov txheej txheem, kev saib xyuas SCADA, thiab kev tswj cov kab ntau lawm. Tus naj npawb ntawm cov channel thiab cov txheej txheem tso tawm tuaj yeem hloov kho raws li qhov ntsuas qhov system.
Cov kauj ruam installation
* Qhib FCS txee: tua lub hwj chim ntawm FCS thiab qhib lub txee qhov rooj raws li kev khiav hauj lwm cov lus qhia ntawm lub txee.
* Xaiv lub qhov: Nrhiav qhov qhib hauv FCS uas tsim nyog rau kev txhim kho AAI543-S00 module. Xyuas kom tseeb tias hom thiab tus naj npawb ntawm lub qhov yog sib xws nrog lub module.
* Ntxig lub module: Tuav ob sab ntawm lub module thiab ntxig lub module smoothly mus rau hauv qhov chaw xaiv. Ua tib zoo saib xyuas qhov kev taw qhia ntawm lub module thiab kev sib dhos ntawm lub interface, thiab xyuas kom meej tias lub module yog tag nrho tso rau hauv lub qhov thiab muab xauv rau hauv qhov chaw.
* Txuas lub cable: Txuas lub teeb liab cable txuas nrog lub teb ntaus ntawv mus rau lub davhlau ya nyob twg ntawm AAI543-S00 module raws li qhov xav tau tiag tiag. Nco ntsoov tias lub cable txuas ruaj khov kom tsis txhob xoob lossis tsis sib cuag.
* Kho cov kab hluav taws xob: Siv lub cable clamp lossis lwm yam khoom siv kho kom kho cov cable txuas nrog lub module kom tiv thaiv lub cable los ntawm kev co lossis rub.
* Kaw lub qhov rooj txee: Tom qab kev teeb tsa tiav, kaw thiab kaw lub qhov rooj txee.
* Rov qab lub zog: Tig rau lub zog ntawm FCS thiab tos kom lub kaw lus pib thiab kuaj xyuas cov module tshiab.
