5437-672yog cov khoom siv hauv teb uas tuaj yeem muab kev sib txuas rau cov sensors, actuators, lossis lwm yam khoom siv hauv teb. Lub module muab kev sib txuas lus interfaces tso cai rau kev sib pauv ntawm cov ntaub ntawv analog thiab digital teeb liab nrog kev tswj hwm. Lub module muab cov tswv yim sib txawv / tso zis (I / O) teeb liab hom uas tuaj yeem suav nrog analog (4-20 mA, 0-5V) hom teeb liab thiab hom teeb liab digital. Lub module tuaj yeem hloov kho rau ntau hom kev lag luam machinery.
Xyoo 1997, Woodward tsim ib qho me me DIN-rail- mountable lim uas yog tsim tshwj xeeb los tshem tawm cov suab nrov tsim los ntawm tus actuator excitation nyob rau hauv ib tug nruj zaus band (notch) nyob ib ncig ntawm 3000 Hz. Chav tsev yuav tsum muaj li 1 nti (25 hli) ntawm DIN rail qhov chaw nyob rau hauv lub actuator FTM, thiab muaj ob lub xov tooj sib txuas. Ib lub xaim txuas los ntawm TB 1 mus rau lub actuator excitation (–), uas ntawm Woodward FTM 5437-672 yog davhlau ya nyob twg TB 6. Qhov thib ob hlau txuas ntawm TB 4 mus rau hauv av.
| Technical Specifications | |
|
Hom |
WOODWARD |
|
Qauv |
5437-672 |
| Kev piav qhia | NetCon Field Terminal Module |
|
Kev sib txuas lus raws tu qauv |
CAN J1939 / Modbus RTU |
| Analog tswv yim | 8 channel |
| Digital I/O | 12 channels |
|
Keeb kwm |
Teb chaws USA |
|
Dimension |
10 * 10 * 8cm |
|
Qhov hnyav |
0.25 kg ib |
System{0}}cov khoom lag luam
Cov khoom "WOODWARD 5437-672" belongs rau NetCon Field Terminal Module (FTM), thiab nws lub luag haujlwm tseem ceeb yog:
Txuas rau ntawm - khoom siv ↔ Tswj System (DCS / PLC / MicroNet)
5437-672 feem ntau tsis yog siv ib leeg xwb; Nws yuav tsum tau ua ke nrog cov txheej txheem system:
MicroNet Controller
5400 Series Control Unit
Tus tswj
Analog Input Module
Digital tso zis module
I/O module
24V DC fais fab mov module
Tsis siv neeg fais fab system
Lub zog module
NetCon kev sib txuas lus module
Muaj tsheb npav interface
Kev sib txuas lus module
Sensor (kub / siab)
Actuator (valve / tsav)
HIGH QUALITY SERVICES
Shielded teeb liab cable
Terminal thaiv
Kev sib txuas lus kab
Cables thiab Accessories
Installation thiab siv
Tsau 5437-672
Muab tso rau hauv lub txee tswj los yog khib
Kev sib txuas fais fab
Txuas mus rau 24V DC fais fab mov
Ntawm - qhov chaw teeb liab teeb liab
Txuas cov khoom siv hauv qab no:
Analog kom muaj nuj nqis: 4-20mA / 0-5V
Digital quantity: Switching signal
Ceev teeb liab: Electromagnetic sensor
Kev sib txuas lus
Kev sib txuas lus yog txuas nrog:
MicroNet Controller
PLC / DCS System
Txoj kev sib txuas lus:
Modbus RTU
TSI J1939
Software thiab parameter configuration
Cov khoom tseem ceeb configuration:
Chaw nyob sib txuas lus (Node ID) Baud tus nqi
Hom Input/Output
Calibration Parameters
Debugging txheej txheem:
Fais fab - ntawm kev tshuaj xyuas ntawm LED xwm txheej
Ntsuas kev sib txuas lus rau normality
Txheeb xyuas cov cim input
Paub meej cov zis tswj
Related Taw Qhia
Woodward Notch Lim:
Siv Tus Naj Npawb: 5437-845
Daim duab kos duab: 9933-651
2 Channel Actuator Controller Module 5501-428, -429, -430, -431, -432
NetCon, MicroNet, thiab MicroNet Plus tswj cov tshuab nrog ntau 2 CH Actuator modules (ib feem naj npawb 5501-428, -429, -430, -431, 432) muaj peev xwm rau 'sib ntaus' zaus tsim nyob ib ncig ntawm 3000 Hz. Cov teeb liab no tuaj yeem tsim suab nrov hauv lub chassis thiab tau paub tias yuav ua rau muaj kev hloov pauv hauv cov teeb liab qis xws li RTDs thiab thermocouples. Nws tuaj yeem ua rau muaj suab nrov ntawm lwm cov cim analog ib yam.
Lub hauv paus ntawm qhov teeb meem yog tias txhua tus actuator module tsim cov lus tawm tswv yim (xws li LVDT lossis RVDT) cov teeb liab excitation uas yog ywj siab thiab asynchronous los ntawm lwm cov actuator modules tsim tib cov zis. Txij li cov teeb liab no yuav zoo li me ntsis offset nyob rau hauv zaus thiab amplitude, nws muaj peev xwm hais tias ib tug sib raug zoo zaus zaus tuaj yeem txhim kho ntawm lub chassis backplane thiab ntawm cov kab analog.
Woodward's engineering services pab pawg pom zoo kom siv ib qho Notch Filter ib chassis rau txhua lub chassis uas siv ob lossis ntau dua actuator modules. Nyob rau hauv cov ntaub ntawv ntawm ib tug redundant system, ob lub lim tuaj yeem ntsia tau los xyuas kom meej tias qhov kev tiv thaiv no muaj nyob rau hauv txhua qhov kev khiav haujlwm. Yog tias lub kaw lus tswj hwm muaj ntau lub chassis, txhua lub chassis ua tau raws li cov qauv no yuav tsum muaj lub lim dej.
