Khoom Taw Qhia

1746-OX8 yog ib qho kev tiv tauj digital tso zis module ntawm SLC 500 series ntawm Allen-Bradley (Rockwell Automation). Nws tuaj yeem siv rau hauv kev lag luam fais fab, kev lag luam elevator, chaw nres tsheb, tsheb thiab tsheb accessories, pub kev lag luam, aluminium smelting machinery, tub yees kev lag luam, steel kev lag luam, combustion tswj system, non-ferrous hlau smelting, iav kev lag luam, engineering machinery, textile machinery, dej kho, thiab lwm yam teb.

Allen Bradley 1746-OX8

Technical Specifications

Tsim	Allen Bradley
Qauv	1746-XIV 8
Kev piav qhia	Tso zis Module
Kev khiav hauj lwm voltage	5 - 125 VDC; 5 - 265 VAC
Cov zis channel suav	Yim ywj siab tso zis
Ua haujlwm kub	0-60 degree
Keeb kwm	Teb chaws USA
Dimension	25 * 20 * 6cm
Qhov hnyav	0.3kg ib

Khoom Paub meej

Raws li ib qho kev nthuav dav tso tawm hauv SLC 500 tswj qhov system, 1746-OX8 muab 8 siab-tam sim no, ib tus neeg raug rho tawm relay tso tawm raws. Txhua qhov chaw tso zis tuaj yeem tsav ntau yam ntawm - qhov chaw thauj khoom (xws li teeb, relay coils, contactors, thiab lwm yam). Factory AB tshaj tawm rau lub Cuaj Hlis 30, 2024, tias kev tsim khoom ntawm 1746-OX8 tau raug tso tseg. Xav txog kev siv cov niaj hnub SLC series relay output module los yog ControlLogix/CompactLogix tso zis module hloov. Raws li qhov yuav tsum tau ua ntawm lub kaw lus, xaiv cov transistor lossis cov khoom tsim tawm hauv lub xeev, thiab tau txais cov software sib xws thiab kev txhawb nqa programming.

1746-OX8 Khoom nta:
Cov zis siab tam sim no: 8 tus kheej raug rho tawm siab tam sim no relay tiv tauj cov zis kom tau raws li ntau yam kev xav tau.
Dav voltage ntau: Txhawb DC 5-125V thiab AC 5-265V kev khiav hauj lwm voltages, muaj zog siv tau.
Kev ua tau zoo ntawm kev sib cais: Nrog kev sib cais voltage ntawm 1500V, nws tuaj yeem tiv thaiv hluav taws xob cuam tshuam zoo.
Kev ntseeg siab: Ua raws li CS-232 NEMA cov qauv, muaj lub suab nrov zoo, thiab tuaj yeem ua haujlwm nyob rau hauv ib puag ncig hnyav, xws li Chav Kawm 1, Division 2 daim ntawv pov thawj hauv cov chaw muaj kev phom sij.

Hauv PLC tswj qhov system, lub luag haujlwm tseem ceeb ntawm 1746-OX8 tso zis module yog hloov cov logic tso zis tawm tswv yim tawm los ntawm lub hauv paus ua haujlwm (CPU) rau hauv qhov chaw muaj qhov hloov hluav taws xob, thiab tsav cov khoom siv ua tiav (xws li relays, taw qhia teeb, solenoid li qub, thiab lwm yam). Lub SLC 500 series siv lub tsheb npav rov qab los sib txuas lus nrog CPU thiab faib cov khoom siv hluav taws xob.

1746-OX8 yog tsim los muab tso rau hauv qhov chaw ntawm tus qauv SLC 500 chassis (1746 Chassis). Lub chassis no feem ntau muaj ntau lub slotso, ts nrog rau PLC CPU, input module, tso zis module, kev sib txuas lus module, thiab lwm yam.

1746-OX8

Configuration ntawm 1746-OX8 hauv RSLogix 50

Thaum teeb tsa 1746-OX8 hauv Allen-Bradley RSLogix 500 software, cov kauj ruam tseem ceeb yog raws li hauv qab no:

✅ Tsim ib qhov project.
Hauv RSLogix 500, tsim lossis qhib koj qhov project SLC 500 PLC.

✅ Ntxiv kho vajtse module
Nkag mus rau I/O Configuration:
Nthuav koj khib (Rack) nyob rau sab laug ntoo -zoo li qauv.
Txoj cai- nyem rau ntawm qhov sib txuas thiab xaiv "Tshiab Module".
Xaiv 1746-OX8 (8-point digital relay output module) los ntawm lub tsev qiv ntawv module.

✅ Teem module parameters

Hom Module	1746-XIV 8
Qhov	Qhov tiag hardware slot tooj
xwm txheej	Pab tau
I/O Base	Tsis siv neeg los yog phau ntawv faib

✅ Kev Tshaj Tawm Tshaj Tawm hauv PLC Program

Nyob rau hauv ib tug rung (logic ntaiv), tswj 0th tso zis:

XIC I:0/0 ---- OTE O:1/0

Kev piav qhia: Thaum cov tswv yim I: 0/0 (ib lub pob lossis hloov pauv) tau teeb tsa rau ON, tso zis O: 1/0 ua cov khoom siv hluav taws xob, yog li tsav 0th tso zis ntawm 1746-OX8.

Cov zis chaw nyob hom O: 1/0 hauv RSLogix 500 qhia:
O - Digital Output

1 - Module slot tooj (raws li tau teev los ntawm koj hauv I/O configuration)
0 - Channel naj npawb (0 txog 7 sib raug rau 8-point tso zis)

✅ Debugging thiab saib xyuas

Hauv online hom:
Saib xyuas cov xwm txheej ntawm txhua qhov chaw tso zis (txawm tias lub thawv OUT sib thooj yog illuminated).
Thaum lub sijhawm ua haujlwm zoo, sim seb qhov ntawm - qhov chaw tso tawm ua raws li qhov kev pab cuam teb.
Cov lus teb rau ntawm qhov taw qhia teeb pom kev zoo ntawm qhov kev soj ntsuam module.
Tom qab ua tiav qhov kev ua haujlwm tiag tiag, nws tuaj yeem tshawb xyuas seb cov khoom siv ntawm qhov chaw thauj khoom puas teb raug.

Yam qauv

1746-V8	1746-OV 16	1746-16
1746-XIV 4	1746-XIV 8	1746-XIV 16
1746-XIV 8	1746-4 IB	1746-8 IB

Cim npe nrov: 1746-OX8,1746-OX8 Output Module, Allen Bradley 1746-OX8,1746 Digital DC Output Module, SLC 500 1746-OX8
