Khoom Taw Qhia
IS420ESWAH3A yog ib qho kev lag luam Ethernet hloov tshwj xeeb uas tsim los ntawm General Electric (GE) rau nws cov kev lag luam automation platform. Nws yog ib qho ntawm cov khoom ntawm GE Mark VIe / Mark VIeS tswj kev sib txuas lus network. Nws yog tsuas yog siv los muab kev ruaj khov thiab txhim khu kev qha Ethernet cov ntaub ntawv sib pauv muaj peev xwm ntawm cov tswj, I / O modules, thiab kev ua haujlwm cuam tshuam.
Technical Specifications
|
Tsim |
General Electric (GE) |
|
Qauv |
IS420ESWAH3A |
| Tshooj Naj Npawb | IS420ESWAH3A Rev.C |
|
Kev piav qhia |
Mark VI Ethernet / IONet Hloov |
|
Keeb kwm |
Teb chaws USA |
|
Dimension |
30 * 20 * 6cm |
|
Qhov hnyav |
0.55 kg ib |
Khoom Paub meej
IONet Hloov IS420ESWAH3A txhawb nqa GE IONet series ntawm cov txheej txheem kev sib txuas lus hauv kev lag luam, uas ua kom zoo dua -cov ntaub ntawv sijhawm sib pauv thiab pab ua tiav cov lus teb thiab kev sib koom tes ntawm ntau lub zog ntawm kev tswj hwm. Nws yog feem ntau deployed ntawm lub hauv paus ntawm kev tswj network thiab xa cov ntaub ntawv ntawm tus maub los thiab teb modules.
Qhov chaw nres nkoj teeb tsa ntawm IS420ESWAH3A feem ntau suav nrog:
8 10/100Base-TX tooj liab cable RJ-45 chaw nres nkoj: Muab cov qauv Ethernet cable interfaces, txhawb kev sib tham ceev ceev (10/100 Mbps) thiab hom puv / ib nrab duplex. New-Gen Automation Limited
Tsis zoo li cov qauv fiber ntau qhov chaw nres nkoj: Tsis zoo li qee cov qauv nrog optical fiber uplinks, IS420ESWAH3A version tsuas yog siv tooj liab cable chaw nres nkoj rau kev sib txuas lus; qee qhov kev lag luam versions tuaj yeem nthuav dav kev sib txuas ntawm fiber ntau los ntawm cov khoom siv ntxiv.
8 10/100Base-TX tooj liab cable RJ-45 chaw nres nkoj: Muab cov qauv Ethernet cable interfaces, txhawb kev sib tham ceev ceev (10/100 Mbps) thiab hom puv / ib nrab duplex. New-Gen Automation Limited
Tsis zoo li cov qauv fiber ntau qhov chaw nres nkoj: Tsis zoo li qee cov qauv nrog optical fiber uplinks, IS420ESWAH3A version tsuas yog siv tooj liab cable chaw nres nkoj rau kev sib txuas lus; qee qhov kev lag luam versions tuaj yeem nthuav dav kev sib txuas ntawm fiber ntau los ntawm cov khoom siv ntxiv.
GE cov khoom lag luam ntawm kev lag luam, tsis muaj kev tswj hwm Ethernet 10/100 keyboards, ESWA thiab ESWB, tshwj xeeb yog tsim los ua kom tau raws li qhov xav tau ntawm cov kev xav tau tiag tiag -lub sij hawm kev lag luam tswj kev daws teeb meem thiab xav tau rau txhua qhov IONet keyboards siv hauv Mark * VIe thiab Mark VIeS Kev Tswj Xyuas Kev Nyab Xeeb. Yuav kom ua tau raws li qhov yuav tsum tau ua kom nrawm thiab ua haujlwm, cov yam ntxwv hauv qab no tau muab:
• 802.3, 802.3u, thiab 802.3x compatibility
• 10/100 puag tooj liab nrog nws pib sib tham
• Full/half duplex auto-kev sib tham
• 100 Mbps FX uplink chaw nres nkoj • HP-MDIX auto sensing
• LEDs qhia txog cov xwm txheej ntawm Link Presence, Kev Ua Haujlwm, thiab Duplex, thiab Ceev rau ib qhov chaw nres nkoj (txhua LED muaj ob xim)
• LED los qhia txog lub hwj chim
• Yam tsawg kawg nkaus 256 KB tsis nrog 4 K media access control (MAC) chaw nyob
• Cov khoom siv hluav taws xob rov ua dua (Diode-OR'd)
IS420ESWAH3A Flow Control (Pause)
Qhov hloov pauv txhawb kev khiav ntawm cov keyboards. Nws siv sivIEEE®- tau txiav txim siab pob ntawv nres kom tau txais thiab hwm cov pob ntawv nres. Qhov hloov pauv tsuas yog xa cov pob ntawv nres yog tias nws xav tau kev tswj hwm ntawm qhov chaw nres nkoj.
IS420ESWAH3A Kev ntseeg tau thiab kev ua tau zoo
Vim tias muaj kev ntseeg siab yog qhov tseem ceeb rau txhua qhov kev tswj xyuas kev lag luam, qhov hloov pauv ntau tshaj 4 lab teev Lub Sijhawm Nruab Nrab Nruab Nrab Tsis Ua Haujlwm (MTBF) ntawm 35℃(95℃F) ambient kub, hauv av ruaj khov ib puag ncig. Qhov hloov pauv kuj ua tau raws li cov qauv kev ua haujlwm hauv qab no:
| Yam khoom | Kev piav qhia |
| Hloov latency | Hloov pob ntawv latency tsis pub dhau daim ntawv thov txwv. |
| Hloov architecture | Cov kev hloov pauv txhawb nqa cov khw- thiab - rau pem hauv ntej architecture, muab cov ntaub ntawv siab. |
| Inrush tam sim no | Qhov hloov pauv muab lub peev xwm pib muag uas txwv tsis pub muaj kev cuam tshuam tam sim no tsawg dua 200% ntawm qhov kev ua haujlwm tam sim no. |
| Mounting | Lub qhov rooj hloov pauv tuaj yeem ua vaj huam sib luag -mounted (hloov mounts rau sab nraub qaum ntawm lub vaj huam sib luag nrog lub bracket) lossis DIN-rail mounted. DIN-rail mounting raws li kev vibration thiab shock specifications. Cov neeg siv kev sib txuas yog siv tau dawb nrog ob hom kev sib txuas. |
| Kev sib txuas fais fab | Txhawb ob lub diode tsis tu ncua-OR'd lub zog hluav taws xob nkag ntawm 18 txog 36 V dc |
| Txias | Convection-cooled thaum mounted vertically lossis horizontally |
| Txheej | IEC 60721-3-3 Chav Kawm 3C2 |
| Ua haujlwm kub | -30 txog 65℃(-22 txog 149℃F) |
| Shipping, cia kub | -40 txog 85℃(-40 txog 185℃F) |
| Cov av noo | Ua haujlwm nyob rau hauv 5 mus rau 95% txheeb ze av noo tsis yog -condensing ib puag ncig yam tsis muaj qhov kub thiab txias los yog av qeeg excursions |
| Seismic vibration | Raws li Universal Building Code (UBC) |
Muaj Versions:
| Yam khoom | Kev piav qhia |
| IS420ESWAH3A | 8-chaw nres nkoj 10/100 puag tooj liab nkaus xwb |
| IS420ESWBH3A | 16-chaw nres nkoj 10/100 puag tooj liab nkaus xwb |
| TIAB SA 420ESWAH1A | 8-chaw nres nkoj 10/100 puag tooj liab nrog ib qho 100 Mbps 100 puag FX fiber-optic uplink, LC-hom kev sib txuas |
| IS420ESWAH2A | 8-chaw nres nkoj 10/100 puag tooj liab nrog ob lub 100 Mbps 100 puag FX fiber-optic uplinks, LC-hom kev sib txuas |
| IS420ESWBH1A | 16-chaw nres nkoj 10/100 puag tooj liab nrog ib qho 100 Mbps 100 puag FX fiber-optic uplink, LC-hom kev sib txuas |
| IS420ESWBH2A | 16-chaw nres nkoj 10/100 puag tooj liab nrog ob lub 100 Mbps 100 puag FX fiber-optic uplinks, LC-hom kev sib txuas |
Thaum siv los hloov pauv, qhov chaw nres nkoj adapter (muab nrog cov khoom siv hloov pauv) yog siv yog xav tau los cuam tshuam qhov SC fiber ntau uas twb muaj lawm rau qhov chaw nres nkoj LC fiber ntau.
