Khoom Taw Qhia
Foxboro ASSY-0301059 yog ib qho tseem ceeb module tivthaiv siv nyob rau hauv industrial tswj teb rau faib tswj systems (DCS). Nws cov haujlwm tseem ceeb suav nrog kev ua haujlwm analog / digital teeb liab, tswj kev txheeb xyuas qhov tseeb, thiab kev sib txuas lus hauv lub cev. Nws tsis tsuas yog tso cai rau kev ua tiav ntawm - thaj chaw tswj cov haujlwm, tab sis tseem ua kom muaj kev ntseeg siab ntawm lub sijhawm ntev - kev saib xyuas online thiab kaw-kho ntawm cov txheej txheem tswj.
Technical Specifications
|
Hom |
FOXBORO |
|
Qauv |
0301059 |
|
Tshooj Naj Npawb |
TIAB SA 0301059 |
|
Kev piav qhia |
DCS PCB / Sib dhos Board |
|
Keeb kwm |
Teb chaws USA |
|
Dimension |
30 * 20 * 6cm |
|
Qhov hnyav |
0, 34kg |
Khoom Paub meej
ASSY 0301059 feem ntau yog siv rau:
✔ Ntawm - qhov chaw tau txais thiab ua cov cim tswj thiab tawm tswv yim / tawm
✔ Kev sib txuas lus thiab cov ntaub ntawv sib koom ua ke ntawm tus tswj hwm thiab lub xaib
✔ Txhawb kev sib xyaw analog / digital teeb liab tau txais thiab tswj cov haujlwm
✔ Ua ib feem ntawm lub logic thiab tswj kev suav ntawm DCS system
✔ Ua tiav qhov kev nthuav dav thiab kev tsim qauv tsim qauv
Raws li lub module ntawm DCS system, nws muaj zog ua cov ntaub ntawv thiab kev sib txuas lus muaj peev xwm. Nws tuaj yeem ua haujlwm hauv kev sib koom tes nrog tus tswj hwm lub ntsiab, tsheb npav (xws li HART / Modbus / Fieldbus), thiab sab sauv -theem systems (SCADA / DCS), ua kom muaj kev sib pauv cov ntaub ntawv thiab tswj kev xa mus.
Technical Parameter Txheej txheem cej luam
ASSY series modules tau nruab nrog siab -cov khoom siv kev ntseeg siab thiab pawg thawj coj saib- qib ntim, uas tsim nyog rau kev ua haujlwm ntev - nyob rau hauv ib puag ncig kev lag luam thiab tuaj yeem txhawb nqa kho vajtse- qib kev ruaj ntseg ntsuas tshuab.
Tsis muaj
Hom teeb liab
Input range
Tso zis ntau yam
Ua haujlwm kub
Cov cim qhia
Analog teeb liab
cov teeb liab
Txhawb kev lag luam teeb liab xws li 0-20 mA thiab ± 10 V
4-20 mA / Digital Communication Output
-40℃rau +80℃thiab siab dua
Kev piav qhia
Core module ntawm kev tswj qhov system
Tau tshaj rau ntawm -site txheej txheem hloov pauv sensors
Txuas nrog lub voj tswj
Feem ntau yoog mus rau ib puag ncig ntawm cov khoom lag luam.
Kev ua cov teeb liab: FOXBORO ASSY 0301059 muaj lub teeb liab ua haujlwm, uas tuaj yeem tau txais thiab ua tiav cov teeb liab sau los ntawm lub sensor, thiab cov txheej txheem thiab pub rov qab raws li kev tswj hwm algorithm.
Kev sib txuas lus interface: Lub module feem ntau muaj kev sib txuas lus nrog lwm cov khoom siv lossis cov tshuab, xws li Ethernet, serial chaw nres nkoj, thiab lwm yam, rau kev sib pauv ntaub ntawv thiab kev saib xyuas tej thaj chaw deb.
Modular tsim: Tus maub los module txais tus qauv tsim, uas yooj yim rau nruab thiab tswj, thiab tuaj yeem hloov kho thiab hloov kho raws li qhov xav tau tiag tiag.
Daim ntawv thov teb: Hom kev tswj hwm no yog siv dav hauv kev lag luam automation, xws li tshuaj lom neeg, roj av, tshuaj, hmoov, er thiab lwm yam kev lag luam, kom ua tiav kev tswj thiab saib xyuas cov txheej txheem kev lag luam.
Los tiv thaiv- muaj peev xwm cuam tshuam: FOXBORO ASSY 0301059 muaj kev ntseeg siab thiab tiv thaiv - muaj peev xwm cuam tshuam, txais cov cuab yeej siv hluav taws xob loj niaj hnub no, thiab cov hluav taws xob hauv hluav taws xob tau txais kev tiv thaiv siab heev - cuam tshuam kev siv tshuab.
Ua kom tiav cov chaw txhawb nqa, kev ua haujlwm zoo meej, muaj zog siv tau: FOXBORO ASSY 0301059 ua tiav nrog cov chaw txhawb nqa thiab cov haujlwm zoo meej, haum rau ntau yam kev lag luam automation tswj kev xav tau.
Hom Kev Taw Qhia:
Foxboro yog ib qho kev lag luam automation thiab cov txheej txheem tswj kev lag luam nrhiav tau nyob rau hauv 1908. Nws lub hauv paus chaw ua haujlwm nyob hauv Foxborough, Massachusetts, Tebchaws Asmeskas. Lub tuam txhab cov khoom lag luam npog tag nrho cov khoom lag luam automation cov khoom lag luam, suav nrog cov txheej txheem automation tswj, faib tswj qhov system (DCS), cov tswj hwm, cov tswv yim / tso tawm modules, sensors, valve positioners, thiab lwm yam. Tom qab xyoo 2014, lub hom tau nkag mus rau Schneider Electric ecosystem thiab txuas ntxiv muab cov khoom tseem ceeb automation thiab kev daws teeb meem rau ntiaj teb txheej txheem kev lag luam los ntawm EcoStrux platform.
Foxboro DCS system feem ntau muaj cov khoom hauv qab no:
➡ Main Controller (Controller/Processor)
➡ Muaj nuj nqi Module/Expansion Card (xws li ASSY-0301059)
➡ Teb I/O Interface Module (Analog/Digital I/O Board)
➡ Field Sensors / Actuators (Pressure Transmitter, Control Valve, thiab lwm yam)
➡ Tib neeg-Machine Interface/Upper-Level Monitoring System (SCADA/Operation Monitoring)
