Khoom Taw Qhia
88FT05C-E GJR2393100R1200 yog siv ua ke nrog 88TK05 chaw nres tsheb npav coupling module rau ob peb lub chaw nres tsheb Procontrol mus rau lub tsheb npav tej thaj chaw deb, yog li paub txog kev sib txuas ntawm qhov chaw nres tsheb Procontrol thiab cov chaw nres tsheb hauv chaw nres tsheb hauv ib qho Procontrol txee.
Kev sib txuas mus rau lub tsheb npav tej thaj chaw deb tuaj yeem ua tiav siv ib lub channel lossis ob txoj kab.
Lub RS485 interface yog tsim los txuas rau qhov siab tshaj plaws ntawm plaub qhov chaw nres tsheb PROCONTROL nyob rau hauv ob lub tshuab ua ke sib txuas.
Kev Ua Tshwj Xeeb
|
Tsim |
Abb |
|
Qauv |
88 FT05C-E |
| Tshooj naj npawb | GJR2393100R1200 |
|
Kev piav txog |
Procontrol Coupling Module |
|
Keeb kwm |
Lub teb chaws Yelemees / Switzerland |
|
Qho loj dav |
30 * 21 * 5cm |
|
Qho hnyav |
0.5 kg |
Khoom Paub meej
88FT05 / R1200 nta:
Cov ntaub ntawv kis thiab saib xyuas: los ntawm RS485 interface tuaj yeem tuaj yeem xa cov ntaub ntawv caij tsheb npav thiab cov ntaub ntawv caij deb nyob hauv ob lub tshuab piav qhia kev sib txuas. Nws tuaj yeem soj ntsuam tus cwj pwm uas tau txais los ntawm cov chaw tos npav kom ntseeg tau tias muaj teeb meem xa tawm cov lus sib kis tau thiab cov xov tooj xa tawm rau cov cim sib tshooj.
Cov teeb liab hloov dua siab tshiab thiab tiam: Lub module tuaj yeem tsim cov teeb liab baseband uas xav tau rau kev xa xov ntawm ob txoj kab ntawm lub tsheb npav nyob deb, nrog rau cov suab nrov uas yuav tsum tau muaj rau kev pom zoo thiab kev tshwm sim. Nws tseem tuaj yeem hloov lub teeb liab biphase ntawm lub tsheb npav tej thaj chaw deb mus rau hauv serial hom teeb liab ntawm RS485 interface, thiab rov ua dua.
Technical parameters:
Interface Hom: Nruab nrog RS485 interface ntawm cov qauv procontrol tej thaj chaw deb nroog kab thiab interface rau txuas nrog 88TK05 chaw nres tsheb npav txuas ntxiv. Cov ntaub ntawv interface ntawm cov qauv yog siv rau cov ntaub ntawv sib txuam nrog 88TK05 chaw nres tsheb npav txuas ntxiv.
Kev ua haujlwm Voltage: +24 V Ua Haujlwm Voltage yog muab rau sab nraud los ntawm Rs485 sab nraud Terminal resistor kuj muaj zog los ntawm 88ft05 module.
Installation thiab siv:
Txoj kev txhim kho: Nws tuaj yeem ntsia tau rau hauv txee ntawm Procontrol tsheb npav system thiab siv nrog 88TK05 chaw nres tsheb npav sib txuas module. Qhov chaw tshwj xeeb thiab cov txheej txheem yuav tsum tau txiav txim siab raws li qhov system configuration thiab cov kev xav tau tiag tiag.
Configuration thiab programming: Feem ntau nws yog qhov tsim nyog los teeb tsa los ntawm cov cuab yeej teeb tsa tshwj xeeb lossis software, thiab teeb tsa cov kev sib txuas lus thiab kev ua haujlwm ntawm cov qauv raws li qhov tshwj xeeb daim ntawv thov scenario thiab cov kev xav tau ntawm lub system.
Hais cov ntaub ntawv
Order no. rau tag nrho module:
Hom Kev Tsim: 88FT05 / r1200
Order No: GJR2393100R1200
Accessories:
Cable 89lK02 rau dual-channel chaw nres tsheb npav coupling
Txiav txim tsis.: Gkwe 602380r0090
