Khoom Taw Qhia
ABB GRBTU-01 (saib naj npawb 3BSE013175R1)yog lub davhlau ya nyob twg chav tsev ntawm kev lag luam automation tswj qhov system lossis Module Termination Unit (MTU). Lub davhlau ya nyob twg chav tsev yog ib qho tseem ceeb nyob rau hauv industrial automation systems, xws li DCS (Distributed Control System), PLC (Programmable Logic Controller), thiab fieldbus systems. Nws ua raws li kev sib txuas ntawm cov module thiab cov khib nyiab backplane, thiab muab lub zog tawm tswv yim, teeb liab kis tau tus mob, thiab qhov system interfaces rau cov tswj module.
Technical Specifications
|
Tsim |
ABB |
|
Qauv |
GR BTU-01 |
| Tshooj Naj Npawb | 3 BSE013175R1 |
|
Kev piav qhia |
Module Terminal Chav |
| Input voltage | 24 V DC yoj |
| Kev khiav hauj lwm qhov kub thiab txias | -20℃~ +70 degree |
|
Keeb kwm |
Sweden |
|
Dimension |
16 * 15 * 8cm |
|
Qhov hnyav |
0, 42kg |
Technical nta
1 . Kev them nyiaj yug kev sib txuas lus thiab raws tu qauv
Txhawb nqa cov txheej txheem kev lag luam (xws li Modbus TCP/RTU, PROFINET, PROFIBUS DP, IEC 61850, thiab lwm yam., nyob ntawm seb lub firmware/application configuration).
Muaj ntau lub cev sib cuam tshuam, xws li Ethernet RJ45, RS-485, thiab Profibus interfaces.
2. Modular installation tsim
Compact me me thiab lub teeb yuag tsim, haum rau kev teeb tsa ntawm DIN ntsia lossis hauv cov khoom tswj.
Qee cov ntawv thov tuaj yeem muab ncaj qha rau hauv ABB CPS / DCS / PLC architecture los ntawm khib.
3. Muaj-qib siv tau
24V DC fais fab mov tsim, haum rau lub hwj chim mov system ntawm industrial tswj txee.
Nws muaj qib IP20 tiv thaiv thiab tsim nyog rau kev lag luam sab hauv tsev.
4. Scalability thiab Compatibility
Nws tuaj yeem txuas nrog ntau yam ntawm -cov cuab yeej siv los tsim cov ntaub ntawv txuas ntawm I/O hauv zos thiab lub hauv paus tswj hwm.
Functional Advantages
✔ Muaj peev xwm hloov dua siab tshiab thiab kev koom ua ke
GR BTU-01 3BSE013175R1 module ua rau muaj kev sib cuam tshuam ntawm cov txheej txheem siv los ntawm - cov cuab yeej siv hauv chaw (xws li Modbus/Profibus/IEC 61850, thiab lwm yam) thiab cov txheej txheem uas yuav tsum tau ua los ntawm kev tswj hwm, yog li txo qhov kev sib tw sib tw ntawm ntawm - cov khoom siv hauv lub vev xaib thiab cov khoom siv loj.
✔ Txhawb ntau lub network topologies
GR BTU-01 3BSE013175R1 module ua ke nrog ntau yam kev sib txuas lus sib txuas lus thiab lub cev chaw nres nkoj, thiab tuaj yeem txuas nrog Ethernet, cov tsheb npav serial thiab fieldbus networks, muab kev hloov pauv ntawm - qhov chaw teeb tsa txoj kev.
✔ System Edge Data Aggregation
GR BTU-01 3BSE013175R1 tuaj yeem ua lub chaw khaws ntaub ntawv tej thaj chaw deb lossis tus neeg saib xyuas ntug, sib sau ua ke thiab teeb tsa cov ntaub ntawv los ntawm ntau yam ntawm - cov khoom siv hauv chaw thiab xa mus rau lub ntsiab tswj qhov system. Qhov no yuav pab txo cov load thiab complexity ntawm lub ntsiab network.
✔ Yooj yim installation thiab xa tawm
Lub compact tsim thiab tus qauv fais fab / kev sib txuas lus interfaces ua rau nws yooj yim rau deploy nyob rau hauv lub tswj txee, thiab kuj pab txhawb kev koom ua ke rau hauv cov kev tswj uas twb muaj lawm.
Siv ABB GRBTU-01 ua ke nrog ABB LDGRB-0.1.
Hauv ABB automation systems (xws li AC 800M / S800 I / O architecture), thaum nws yog ib qho tsim nyog los sib sau ua tiav I / O khib lossis ib qho kev faib tswj ntawm node, GRBTU-01 thiab LDGRB-01 feem ntau yog ob qhov tseem ceeb uas siv ua ke. Lawv feem ua qhov sib txawv hluav taws xob / tsheb thauj mus los thiab kev tiv thaiv kev ruaj ntseg.
GRBTU-01 (Module Termination Unit)
Raws li lub davhlau ya nyob twg ntawm lub module, nws yog tsuas yog siv rau lub teeb liab txiav, hluav taws xob interface, ce thiab fais fab txuas nyob rau hauv lub tswj system khib.
Nws feem ntau yog nyob rau hauv lub ntsiab tswj khib lossis lub hauv paus tseem ceeb, muab kev sib koom ua ke terminals thiab teeb liab bridging zog rau I / O modules, kev sib txuas lus modules, thiab lwm yam.
Chav tsev no ua kom ntseeg tau tias cov teeb liab, lub zog siv hluav taws xob, thiab kev sib txuas ntawm cov khoom siv hluav taws xob ntawm cov module thiab cov txheej txheem tswj tau ruaj khov thiab txhim khu kev qha.
LDGRB-01 (Local Distribution Rack Bus Terminator / I/O Module)
LDGRB-01 yog ib chav tsev tshwj xeeb uas tsim los rau S800 I / O lub tsheb npav txiav tawm ntawm Cov Chaw Muag Khoom Hauv Zos lossis rau kev ua haujlwm analog / digital I / O.
Nws lub luag haujlwm tseem ceeb yog ua qhov kev txiav txim siab rau I / O khib tsheb npav.
